Gravel Bike SRAM Apex 1x12s, GRVL AF

4.5

Looking for freedom and nature? You can safely and confidently head off the beaten path with the 12-speed mechanical SRAM Apex transmission, 45 mm wide tires, and hydraulic disc brakes.

ID 8766974

Sold and shipped by

Checkout as a member and get more time to return products in case you change your mind.
QUEBEC CONSUMERS ONLY: Decathlon Canada Inc. offers a wide selection of repair services, spare parts (in-store and online), and support information, but we do not guarantee their availability under the Consumer Protection Act. The only exceptions are the specific repair services listed below for purchases made on or after October 5, 2025
See more

How to get it

Gravel Bike SRAM Apex 1x12s, GRVL AF 1/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 2/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 3/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 4/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 5/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 6/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 7/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 8/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 9/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 10/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 11/13

Gravel Bike SRAM Apex 1x12s, GRVL AF 12/13

Highlights

Unselected

SRAM Apex XPLR

Built with SRAM’s gravel-dedicated drivetrain, Apex XPLR, the GRVL AF is supremely capable on off-road terrain.
Go exploring

The GRVL AF is adventure-ready with mounting points for a rear rack or extra bottle cages, and a maximum load of 110kg.
Lightweight fork

Dynamic and lightweight, the carbon fork delivers impressive reactivity – and can accommodate up to 50mm tyres.

SRAM Apex XPLR

Built with SRAM’s gravel-dedicated drivetrain, Apex XPLR, the GRVL AF is supremely capable on off-road terrain.

Number of speeds
SRAM Apex 12-speed drive train - 40T single chainring - 11/44 cassette
Braking power
SRAM Apex D1 hydraulic disc brakes -160 mm at the front and rear
Efficiency
Aluminum wheels - Hutchinson Touareg 700x45C tires - tubeless ready
Lightweight
Aluminum frame - Carbon fork - complete bike weighs 10.88 kg (24 lb) in size M
load capacity
Maximum user weight + load: 110 kg (242.5 lb)

Description

Design details

The AF gravel range
The AF gravel is a new bike we’ve developed for your regular gravel rides and your first bikepacking adventures.If you want to get way from it all and have some fun, this bike is for you.The geometry has been improved to make the bike more comfortable and versatile.You can mount tires up to 50 mm wide (in 700!) and head out on long winding trails in search of thrills and freedom.
High-quality and comfortable aluminum frame
The GRVL AF frame is made from double-thickness 6061 aluminum, reducing its weight and making it a more responsive and playful bike. Its geometry was designed for a comfortable ride on gravel. The frame is compatible with tires with a cross section of up to 50 mm. The frame weighs 1,870 g (4.1 lb) in size M.
Carbon fork
The GRVL AF fork is made of carbon for rigidity and propulsion with an aluminum pivot for guaranteed sturdiness.Three side inserts to attach extra bags or bottle carriers to set off on an adventure.The fork is compatible with tires with a maximum cross section of 50 mm.The frame and fork are compatible with fenders and a pannier rack.
Riding positionHandlebar and stem
The GRVL AF 31.8 mm diameter handlebars are made from 6061 T6 aluminum.The 16º flare is perfect for gravel riding, for a comfortable ride and good manoeuvrability.Handlebar width varies depending on bike size: XS - 400 mm S - 420 mm M/L - 440 mm XL - 460 mm The reach is 70 mm and the drop 130 mm.The stem is made from 6061 T6 7º/ -7º aluminum. Stem length according to bike size:XS - 60 mm S - 70 mm M - 80 mm L - 90 mm XL - 100 mm
SRAM Apex 1x12 speed drivetrain
This bike comes with a SRAM APEX single chainring drivetrain and 12 gears. Shifter: SRAM Apex 1x12 Crankset: SRAM Apex 1 D1 DUB WIDE 40T Crank length: Crank Length: XS/S - 165 mm M/L - 172.5 mm XL - 175 mm Rear derailleur: SRAM Apex 12 XPLR D1 Cassette: SRAM APEX XPLR PG-1231 - 12S - 11/44T Chain: SRAM APEX D1 12S - 114 links Crank housing: BSA 68 mm SRAM DUB ROAD
Hydraulic disc brakes.
Hydraulic brakes: SRAM Apex D1 Flatmount Front / rear brakes: SRAM paceline 160 mm centerlock Brake levers: SRAM Apex D1 Pads: SRAM Steel-backed organic Powerful and precise braking through simultaneous activation of two combined brake pads, coupled with highly adjustable settings.
Aluminum wheels designed for offroad biking
6069 aluminum rims Internal width 27 mm External width 31.4 mm Rim height 19 mm 28 spokes Centerlock axle Front thru axle 12x100 mm M12x1.5 Rear thru axle 12x142 mm M12.x1.5 Tubeless ready (kit not included) Wheels compatible with tires 35 mm wide minimum and 50 mm wide maximum.Wheel weight: 1,877 g (4.1 lb)
Versatile Hutchinson Touareg tires
Hutchinson Touareg 45x700 mm tires Weight 590 g (1.3 lb) per tire.Inner tube pressure: min:2.5 bar/36 psi max:3.5 bar/51 psi The tires are have an inner tube but can be changed to tubeless with valves ref 8551979 and sealant ref. 8363393.
Position
Decathlon Comfort 30º saddle Width: 155 mm Length: 250 mm Steel clamp B’TWIN 6061 T6 aluminum seat post Diameter:27.2 mm Height: XS / S: 300 mm M/L/XL: 350 mm The natural flex of the seat post (thanks to its 27.2 diameter) disperses vibrations and impacts for more comfort.
Little things to know about the GRVL AF
Your GRVL AF comes with a box that includes: - Platform pedals, we recommend using clipless pedals to take full advantage of this bike’s performance - 2 brake clips - 1 bell - 1 front and rear light - 1 torque wrench - 1 tube of seat post grease
Bike weight
This configuration with an SRAM Apex drive train weighs approximately:XS: 10.50 kg (23.1 lb) S: 10.70 kg (23.6 lb) M: 10.88 kg (24 lb) L: 10.95 kg (24.1 lb) XL: 10.98 kg (24.2 lb) The maximum load (user+load) is 110 kg (242.5 lb) whatever the bike size.
Care instructions
We recommend against using high-pressure washers to wash your gravel bike to avoid damaging it.We recommend cleaning your gravel bike after each ride, especially after taking on particularly muddy or dusty terrain. In addition, remember to check your tire pressure and braking efficiency before each ride.
Protecting the frame
When using bags or other accessories, you can use the following transparent protective stickers: 8486947. Resistant to temperature variations, water, tears and UV rays.
Choosing the size of your bike
Choose your bike size based on your height and build (arm span and leg length). If you are between sizes, opting for the smaller size will be more comfortable and make it easier to tackle gravel trails. XS: 154–165 cm (5′1″–5′5″) S: 165–173 cm (5′5″–5′8″) M: 173–180 cm (5′8″–5′11″) L: 180–188 cm (5′11″–6′2″) XL: 188–200 cm (6′2″–6′7″)
